YASKAWA AC Servo Motor Driver Servopack Type SGDH-75DE 7.5KW 400V 3 Input PH

Name: YASKAWA AC Servo Motor Driver Servopack Type SGDH75DE 75KW 400V 3 Input PH
Brand: Yasakawa
Price: 1 USD

YASKAWA AC Servo Motor Driver Servopack Type SGDH-75DE 7.5KW 400V 3 Input PH Manufactures

Brand Name : Yasakawa

Model Number : SGDB-15ADP

Place of Origin : Japan

MOQ : 1

Price : negotiable

Payment Terms : T/T, Western Union

Supply Ability : 100

Delivery Time : 2-3 work days

Packaging Details : New in original box

Brand : Yasakawa

Model : SGDB-15ADP

Palce of Origin : Japan

Type : Servopack

Power : 75kW

nput Volatge : 200-230v

Input Frequency : 50/60hz

Input PH : 3

Contact Now

Industrial Servopack NEW ORIGINAL YASKAWA AC SERVO DRIVER SGDH-75DE 7.5KW 400V 3PH

YASKAWA ELECTRIC
SGDH-75DE
SGDH75DE
SERVO AMPLIFIER

7.5KW

400V

3PH
AVAILABLE
REBUILT SURPLUS
NEVER USED SURPLUS
REPAIR YOURS
24-48 HOUR RUSH REPAIR
2 - 15 DAY REPAIR
2 YEAR RADWELL WARRANTY

Speed control range 1:5000
Speed variance
Load variance During 0 to 100% load ±0.01% max. (at rated speed)
Voltage variance Rated voltage ±10%:0% (at rated speed)
Temperature variance 25 ±25 °C: ±0.1 % max (at rated speed)
Frequency characteristics 400 Hz (at JL= JM up to 15 kW drives), 100 Hz (at JL= JM from 22 kW to 55 kW drives)
Torque control accuracy (reproducibility) ±2%
Soft start time setting 0 to 10 s (acceleration, deceleration can each be set.)
Input signal
Speed reference input
Reference voltage ±6 VDC (forward motor rotation if positive reference) at rated speed: set at delivery
Variable setting range: ±2 to ±10 VDC at rated speed/ max. input voltage: ±12 V
Input impedance Approx. 14 kΩ
Circuit time constant Approx. 47 µs
Torque reference input
Reference voltage ±3 VDC (forward rotation if positive reference) at rated speed: set at delivery
Variable setting range ±1 to ±10 VDC at rated torque reference
Input impedance Approx. 14 KΩ
Circuit time constant Approx. 47 µs

The ideal servo family for motion control.

Fast response, high speed, and highaccuracy.
• Online autotuning with 10 levels of rigidity
• Peak torque 300% of nominal during 3 seconds
• Automatic motor recognition
• Analogue control for speed and torque
• Pulse train control for positioning
• Optional units offer network connectivity and flexible

system architecture
• Smooth operation
• Oscilloscope available via software tool
• Windows based configuration and commissioningsoftware

Ratings
• 230 VAC Single-phase 30 W to 1.5 kW (4.77 Nm)
• 400 VAC Three-phase 450 W to 55 kW (350 Nm)

OTHER SUPERIOR PRODUCTS

Yasakawa Motor, Driver SG-	Mitsubishi Motor HC-,HA-
Westinghouse Modules 1C-,5X-	Emerson VE-,KJ-
Honeywell TC-,TK-	GE Modules IC -
Fanuc motor A0-	Yokogawa transmitter EJA-
