Durable Pressure Temperature Transmitter Rosemount 3 Valve Manifold 0305RC53B11

Name: Durable Pressure Temperature Transmitter Rosemount 3 Valve Manifold 0305RC53B11
Brand: Emerson-Rosemount
Price: 120 USD

Durable Pressure Temperature Transmitter Rosemount 3 Valve Manifold 0305RC53B11 Manufactures

Brand Name : Emerson-Rosemount

Model Number : 0305RC53B11

Certification : CE

Place of Origin : Singapore

MOQ : 1

Price : 120 USD

Payment Terms : T/T / Paypal

Supply Ability : 50

Delivery Time : 1-2 week

Packaging Details : New Original Box

Category : Transmitter Spare Parts

Type : Manifold

Species : 3Valve

Maximum Operating Temperature : 1000°F (538°C)

Manifold Material : 316 SST/316L SST, Alloy C-276, Alloy 400

Packing Material : PTFE, graphite-based

Process Connection Orientation : Parallel with transmitter, 90° to transmitter

Warranty : Up to 5-year limited warranty

Contact Now

Rosemount 3 Valve Manifold 0305RC53B11 For Differential Pressure Transmitter

All of Rosemount orders will be ordered acorring to your requirements!

Quick Details:

 Factory assembled, leak-tested, and calibrate
 Full breadth of offering including integral, in-line, and conventional
 Integral design enables “flangeless” connection to instrument
 Block and bleed, 2-, 3-, and 5-valve configurations
 Compact, lightweight design
 Easy in-process calibration
 Direct-mount capability
 Available in NACE®-compliant materials of construction

Specifications:

Maximum Operating Temperature	1000°F (538°C)
Manifold Material	316 SST/316L SST, Alloy C-276, Alloy 400
Packing Material	PTFE, graphite-based
Process Connections	1/4" -18 NPT female, 1/2" -14 NPT female, 1/2" -14 female NPT flange adapter, 12 mm ferrule tube flange adapter
Process Connection Orientation	Parallel with transmitter, 90° to transmitter
Certifications	Cleaning for special services, sour gas (meets NACE MR 0175/ISO 15156, MR0103), see full specs for complete list of certifications
Warranty	Up to 5-year limited warranty

Selection guide

1. Rosemount 305 Integral Manifold
2. Rosemount 304 Conventional Manifold
3. Rosemount 306 In-line Manifold

Rosemount™ 305 Integral Manifold

The Rosemount 305 Integral Manifold attaches directly to the patented Rosemount Coplanar™ transmitter, eliminating the need for a flange. This lightweight, premier manifold comes in a 2-, 3- and 5-valve configuration and allows instrument isolation, controlled venting and added protection from leaking to ensure measurement integrity. This product can be factory-assembled to a transmitter and leak-tested and can be used with multivariable, static and differential pressure transmitters.

Rosemount™ 306 In-Line Manifold

The Rosemount 306 In-Line Manifold is engineered for in-line transmitters. This manifold comes with a male or female threaded NPT process connection and assembles directly to pressure transmitters and gauges for simple in-process calibration. Featuring block-and-bleed and 2-valve configuration for instrument isolation and drain/vent capabilities, this manifold comes factory-assembled to transmitters and gauges, leak-tested and calibrated.

Rosemount™ 304 Conventional Manifold

Engineered for 2-, 3- and 5-valve configurations, the Rosemount 304 Conventional Manifold attaches to a transmitter with a traditional or coplanar flange. This manifold is available in traditional and wafer styles and is factory-assembled to transmitters, leak-tested and calibrated for quick installation. Designed for multivariable, static and differential pressure transmitters, this manifold allows instrument isolation, controlled venting and protection from leaking to ensure measurement integrity.

Durable Pressure Temperature Transmitter Rosemount 3 Valve Manifold 0305RC53B11

Table 1 : Rosemount 305 Integral Manifold Ordering Information ( A part )

Table 2 :Rosemount 306 Pressure Manifold Ordering Information ( A part )

Table 3 :Rosemount 304 Conventional Manifold Ordering Information( A part )

Durable Pressure Temperature Transmitter Rosemount 3 Valve Manifold 0305RC53B11

Drawings of 305 / 306 / 304 Manifold ( A part )

If you need more order information , we can send you the complete datasheet.

Certifications:

1.Certificate of Origin

2.Calibration Certificate

3.Material Traceability Certification

Rosemount items we sold before:

Durable Pressure Temperature Transmitter Rosemount 3 Valve Manifold 0305RC53B11

Good Service in WTL:
>We offer high quality, fast delivery, competitive price for Rosemount.
>Please send your RFQ to get the latest price.
>Normally, we will ship the items in 1-2 weeks after receive the payment.
>We can ship to you by UPS/DHL//EMS/Fedex. Please contact us and we will use your preferred ways.
>We have a large stock and the prices are variable, so sometimes the prices we post are not accurate. If needed, please contact us for specific prices.

Liability:

WTL is not liable for any personal injury or property damage resulting from the use of this equipment. It is

buyer's responsibility as to the safe handling & operation of this equipment and to verify equipment is

compliance to their machinery.
