R88D-GT15H-Z OMRON Servo 50 W up to 15 kW Drive input provides application versatility
At the heart of every great machine
Accurax G5 gives you that extra edge to build faster, accurate, smaller and safer machines. You will gain almost 25% in motor weight reduction and 50% cabinet space saving. You will achieve sub micron precision and ms settling time.
- EtherCAT, MECHATROLINK-II and Analogue/Pulse drive models
- Frequency response of 2kHz
- Safety conforming to ISO13849-1 (PL d)
- High accuracy provided by 20 bit encoder
- Drive Programming: embedded indexer functionality in the Analogue/Pulse models
- Advanced vibration suppression
- Full closed loop encoder built-in
- Double registration input provides application versatility
- Rotary motors from 50 W up to 15 kW
Accurax G5 Built-in positioning with indexer functionality
The Accurax G5 Analogue/Pulse series is supplied with an integrated positioner as standard. The positioner programmability is provided to the user via a Drive Programming environment, and it is ideal for simple positioning solutions like assembly machines, sorting and pick and place applications. The Drive Programming editor is included in the CX-Drive tool.
Full closed loop
• Built-in external encoder input for high accuracy
• The external encoder can be selected between phase AB output and incremental or absolute encoder with serial communication
Programming I/O
• 10 general purpose input signals: up to 5 digital inputs to select the individual commands or sequences, strobe function, run, etc
• 4 general purpose output signals - 1 output signal fixed to alarm output
Programming functionality
• Point-to-point positioning functions
• Position and speed control modes. Torque limit function
• Up to 32 indexing points
• Same positioning performance as with the analogue/pulse input command
Accurax G5 servo system
• Wide range of motors from 50 W up to 15 kW
• High-response frequency of 2 kHz
• Load vibration suppression
• Embedded Safety conforming ISO13849-1 Performance Level d
• Advanced tuning algorithms (Anti-vibration function, torque feedforward, disturbance observer)
• Drives available for multi axes applications with EtherCAT built-in
| R88M-G10030S-S2 | R88M-G20030S-S2 |
| R88D-GTA5L | R88D-GT01L |
| R88D-GT02L | R88D-GT04L |
| R88D-GT01H-Z | R88D-GT02H-Z |
| R88D-GT04H-Z | R88D-GT08H-Z |
| R88D-GT10H-Z | R88D-GT15H-Z |
| R88D-GT20H-Z | R88D-GT30H-Z |
| R88D-GT50H-Z | R88D-GT75H-Z |
| R88D-GT01H-Z | R88D-GT02H-Z |
| R88D-GT04H-Z | R88D-GT08H-Z |
| R88D-GTA5L | R88D-GT01L |
| R88D-GT02L | R88D-GT04L |
| R88D-GTA5H-Z | R88D-GT01H-Z |
