Brand Name : ABB
Model Number : CI592-CS31 1SAP221200R0001
Certification : CE
Place of Origin : Germany (DE)
MOQ : 1
Price : contact us
Payment Terms : T/T
Supply Ability : 100
Delivery Time : 3-5 working day
Packaging Details : New Original Box
Pienin tilauserä : 1 piece
Input Current : 5 mA
Gross Weight : 0.149 kg
Country of Origin : Germany (DE)
Product Main Type : CI592
Output : Transistor
Deliver time : 3-5 working day
warranty : one year
Brand : ABB
CI592-CS31 1SAP221200R0001 ABB CI592-CS31 4016779681087 0.149 kg CI592 24 V DC
European Article Number | 4016779681087 |
Produced in | - |
Name | CI592-CS31 |
ID | 1SAP221200R0001 |
Dimensions | 54 mm x 76 mm x 68 mm |
Weight | 0.15 kg |
Сustoms Tariff Code | 85389091 |
Digital I/Os Limit | 240 DI, 240 DO |
Connections | Bus module with Onboard IO - 8DI / 8DO-T / 4AI / 2AO |
Analog I/Os Limit | 32 AI, 32 AO |
Outputs | 2 channels, 0 ... 20mA, 4 ... 20mA, -10 ... +10V, max. 2 current outputs, 11bit + sign |
Input Voltage | 24 V DC |
Nominal Nominal Current | 0.5 A |
Nominal Output Voltage | 24 V DC |
Fieldbus Interface | CS31 Slave |
Power Supply | 24 V DC |
Hardware Counters | 2 |
Software | AC500 Control Builder PS501-PROG |
Ingress Protection Rating | IP20 |
Serial Port №2 | I/O-Bus |
Digital Inputs DC 24V | 8 |
Serial Port №1 | CS31, RS485 interface |
Extra Functions | Integrated Fast counter |
Mounting Style | Horizontal, Vertical possible with derating |
Secondary Current Strength | 0.2 A |
Digital Configurable I/Os | 8 |
Nominal Voltage | 24 V DC |
Hardware Counter Input Frequency Limit | 50 kHz |
DIN Mounting | TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715 |
Inputs | 4 channels, 0 ... 20mA, 4 ... 20mA, -10 ... +10V, 0 ... +10V, PT100, PT1000, NI1000, usable as DI, 11bit + sign |
