ABB 07DC92 Digital I O Module GJR5252200R0101 24 V DC IP20 Small Equipment

Brand Name : ABB

Model Number : GJR5252200R0101

Certification : CE

Place of Origin : Germany (DE)

MOQ : 1 piece

Price : contact us

Payment Terms : T/T

Supply Ability : 100

Delivery Time : 3-5 working day

Packaging Details : New Original Box

Brand : ABB

Gross Volume : 0 dm³

Gross Weight : 0.3 kg

Country of Origin : Germany (DE)

Product Main Type : 07DC92

Maximum Operating Altitude Permissible : 2000 m

Output Voltage (Uout) : 24 V DC

Input module : 24

Output module : 24

Part Type : New

Contact Now

GJR5252200R01 ABB 07DC92 07DC92 Dig. In-/Output module 24 0.3 kg 0 dm³ 32151705

General Information:

Product ID:	GJR5252200R0101
ABB Type Designation:	07DC92
Catalog Description:	07DC92 Dig. In-/Output module, 24

Categories	Products » PLC Automation » Legacy products » AC31 and previous series » AC31 I/Os and previous series

Additional Information:

ABB Type Designation:	07DC92
ABS Certificate:	1SAA960000-0102
Ambient Air Temperature:	Operation 0 ... +55 °C
Ambient Air Temperature:	Storage -25 ... +75 °C
CS31-Bus:	1
CSA Certificate:	1SAA960000-1102
Cable Cross-Section:	0.08 ... 1.5 mm²
Core Credit:	0
Country of Origin:	Germany (DE)
Customs Tariff Number:	85389091
DNV Certificate:	1SAA960000-0304
Data Sheet, Technical Information:	2CDC122006D0201
Declaration of Conformity - CE:	1SAD938505-0047
Degree of Protection:	IP20
Environmental Information:	1SAA960001-2401
Fieldbus Interface Type:	CS31 Slave
GL Certificate:	1SAA960000-0401
Gross Volume:	0 dm³
Gross Weight:	0.3 kg
I/O Option:	Bus module with Onboard IO - 32DC
Instructions and Manuals:	2CDC120059M0202
Invoice Description:	07DC92 Dig. In-/Output module, 24
LR Certificate:	1SAA960000-0502
Made To Order:	No
Maximum Operating Altitude Permissible:	2000 m
Minimum Order Quantity:	1 piece
Mounting on DIN Rail:	TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715
Mounting on DIN Rail:	TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715
Number of Analog Configurable I/Os:	0
Number of Digital Configurable I/Os:	32
Object Classification Code:	K
Order Multiple:	1 piece
Output Current:	0.5 A
Output Voltage (Uout):	24 V DC
Part Type:	New
Primary Voltage:	24 V
Product Depth:	85 mm
Product Main Type:	07DC92
Product Name:	07DC92 Dig. In-/Output module, 24
Product Net Depth / Length:	0 mm
Product Net Height:	0 mm
Product Net Length:	0 mm
Product Net Weight:	0.3 kg
Product Net Width:	0 mm
Product Type:	Spare_Parts
Quote Only:	No
RINA Certificate:	1SAA960000-0802
RMRS Certificate:	1SAA960000-0702
RoHS Information:	1SAA960005-4401
RoHS Status:	No declaration needed
Selling Unit of Measure:	piece
Serial Port 1 Type:	RS-485, CS31
Short Description:	07DC92:AC31,Digital I/O module
Stocked At (Warehouses):	Menden, Germany
	Ladenburg, Germany
	New Berlin,Wisconsin, United States
Supply Voltage:	24 V DC
Technical Information:	Decentral AC31-IN- /Outputmodule
Technical Information:	Supply voltage. 24 V DC, Screw terminal
Terminal Type:	Screw Terminals, Pluggable
UL Certificate:	1SAA960000-1602
UNSPSC:	32151705
WEEE B2C / B2B:	Business To Business
WEEE Category:	5. Small Equipment (No External Dimension More Than 50 cm)
eClass:	27-24-22-04
