Panasonic MADLN15SG Industrial Servo Drives Output / Input: 200W / 200V

Name: Panasonic MADLN15SG Industrial Servo Drives Output Input 200W 200V
Brand: Panasonic
Price: 1 USD

Panasonic MADLN15SG Industrial Servo Drives Output / Input: 200W / 200V Manufactures

Brand Name : Panasonic

Model Number : MADLN15SG

Certification : CE

Place of Origin : Japan

MOQ : 1

Price : Contact

Payment Terms : T/T, Western Union,paypal

Delivery Time : 3-5days

Packaging Details : new and original

Brand : Panasonic

Modenl number : MADLN15SG

Country of origin : Japan

AC Voltage : 200V

Frequency response : 3.2 kHz

Current - Output : 6A

Supply voltage : Single/3-phase 200 V

Type : Industrial Servo Drives

Series : A6SF series

Mass (kg) : 0.8

Contact Now

Panasonic MADLN15SG Industrial Servo Drives Output / Input: 200W / 200V

Product Description

MADLN15SBrand: Panasoni

Model: MADLN15S

Output / Input: 200W / 200V

MSMF012L1U2M 100W

MSMF Motor without brake

MSMF012L1V2M Motor with brake

MSMF012L1U1M Motor without brake

MSMF012L1V1M Motor with brake

MADLT05SF All in one Amplifier

MADLN05SE Pulse Amplifier

MADLN05SG Communication type Amplifier

MSMF042L1U2M 400W

MSMF, MHMF Motor without brake

MSMF042L1V2M Motor with brake

MHMF042L1U2M Motor without brake

MHMF042L1V2M Motor with brake

MSMF042L1U1M Motor without brake

MSMF042L1V1M Motor with brake

MBDLT25SF All in one Amplifier

MBDLN25SE Pulse Amplifier

MBDLN25SG Communication type Amplifier

MSMF082L1U2M 750W

MSMF, MHMF Motor without brake

MSMF082L1V2M Motor with brake

MHMF082L1U2M Motor without brake

MHMF082L1V2M Motor with brake

MSMF082L1U1M Motor without brake

MSMF082L1V1M Motor with brake

MCDLT35SF All in one Amplifier

MCDLN35SE Pulse Amplifier

MCDLN35SG Communication type Amplifier

MDMF102L1G6M 1KW

MDMF Motor without brake

MDMF102L1H6M Motor with brake

MDDLT45SF All in one Amplifier

MDDLN45SE Pulse Amplifier

MDDLN45SG Communication type Amplifier

MDMF152L1G6M 1.5KW

MDMF Motor without brake

MDMF152L1H6M Motor with brake

MDDLT55SF All in one Amplifier

MDDLN55SE Pulse Amplifier

MDDLN55SG Communication type Amplifier

MSMF102L1G6M 1KW

MSMF Motor without brake

MSMF102L1H6M Motor with brake

MDDLT55SF All in one Amplifier

MDDLN55SE Pulse Amplifier

MDDLN55SG Communication type Amplifier

MSMF152L1G6M 1.5KW

MSMF Motor without brake

MSMF152L1H6M Motor with brake

MDDLT55SF All in one Amplifier

MDDLN55SE Pulse Amplifier

MDDLN55SG Communication type Amplifier

MHMF102L1G6M 1KW

MHMF Motor without brake

MHMF102L1H6M Motor with brake

MDDLT45SF All in one Amplifier

MDDLN45SE Pulse Amplifier

MDDLN45SG Communication type Amplifier

MHMF152L1G6M 1.5KW

MHMF Motor without brake

MHMF152L1H6M Motor with brake

MDDLT55SF All in one Amplifier

MDDLN55SE Pulse Amplifier

MDDLN55SG

Communication type Amplifier

Panasonic MADLN15SG Industrial Servo Drives Output / Input: 200W / 200V

RS485 1: n communication (max 31)

Safety function A dedicated connector is provided for Functional Safety.

Front panel (1) 5 keys

(2) LED (6-digit)

Regeneration A-frame, B,-frame: no built-in regenerative resistor (external resistor only)

C-frame to F-frame: Built-in regenerative resistor (external resistor is also enabled.)

Dynamic brake A-frame to F-frame: Built-in

Control mode Switching among the following 7 mode is enabled,

(1) Position control

(2) Speed control

(3) Toque control

(4) Position/Speed control

(5) Position/Torque control

(6) Speed/Torque control

(7) Full-closed control

Contact person: Anna

E-mail: wisdomlongkeji@163.com

Cellphone: +0086-13534205279

The following are some of the drive models, both new and used are stocked:

MSDA3A3A1A MSDA5A3A1A MSDA013A1A
MSDA023A1A MSDA043A1A MSDA083A1A
MDDA103A1A MDDA153A1A MDDA203A1A
MDDA253A1A MDDA303A1A MDDA353A1A
MSDA403A1A MSDA503A1A MSD023A1XXV
MSDA083A1XXV MSD043A1X MSDA043D1A
MQDA043A1A MUDS043A1A MUDS023A1A
MUDS083A1A MUMS082A1E0S MUDS083A1M
MUMA012P1T MUMA022P1T MUMA042P1T
MUMA042P1S MUMA012P1S MUMA022P1S
MUMS082P1S MSDA043A1XXV MSDA013A1XXV
MKDET1505P MLDET2310P MUMA082P1T
MLDET2510P MKDET1310P MUMS042A1AOS
MSM041A211 MQMA042A1E MSMA022P1A
MSM042P1B MSM042AJB MSM011P1N
MQMA022S2P MSM012AJA MSM012P1F
MDMA152S1C MSM042AJA MQMA012C2P
MSMA022A1B MSM021DJE MSD043A1X
MSD043A1XX MSM042A1A MSM5AZA1B
MUMS012C2U1S MUMS012A1F0S MSMZ082A1B
MSD013A1XX MSM012A1A MSMA012C1A
MSDA013D1A MSMA5AZS1A MQMA012P1B
MSMD042P1T MUMS022A1B0S MFM082A1C
MQMA042A1E MSMA022C1A MSMA022C1E

OTHER SUPERIOR PRODUCTS

Yasakawa Motor, Driver SG- Mitsubishi Motor HC-,HA-

Westinghouse Modules 1C-,5X- Emerson VE-,KJ-

Honeywell TC-,TK- Fanuc motor A0-

Rosemount transmitter 3051- Yokogawa transmitter EJA-
